Product Summary

The SP485EN-L/TR is half-duplex transceiver that meet the requirements of RS-485 and RS-422.

Parametrics

Absolute maximum ratings: (1)VCC: ±12V ; (2)Input Voltages: Logic:-0.3V to (VCC+0.5V), Drivers:-0.3V to(VCC+0.5V), Receivers:±15V ; (3)Output Voltages: Logic:-0.3V to (VCC+0.5V), Drivers:±15V, Receivers:-0.3V to (VCC+0.5V) ; (4)Storage Temperature: -65℃ to +150℃; (5)Power Dissipation: 500mW.

Features

Features: (1)+5V Only ; (2)Low Power BiCMOS ; (3)Driver/Receiver Enable ; (4)Slew Rate Limited Driver for; (5)RS-485 and RS-422 Drivers/Receivers.

Diagrams

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
SP485EN-L/TR
SP485EN-L/TR
Exar
RS-485 Interface IC Low Pwr Half-Duplex RS-485
Data Sheet
0-1850: $0.25
1850-2500: $0.23
