Product Summary
The 882N-1CH-C is a Miniature Pcb Power Relay.
Parametrics
882N-1CH-C specifications: (1)Contact material: AgSnO alloy; (2)Contact resistance: 100mΩ Max. (1A(100mA for Au-plating contact)/6VDC by 4 pipes mΩ meter); (3)Operate time: 10ms Max.; (4)Release time: 5ms Max.; (5)Insulation resistance: 100MΩ Min. (DC 500V); (6)Dielectric strength Between open contact: AC 1000V , 50/60Hz 1 min. (typ.), Between contact and coil : AC 4000V, 50/60Hz 1 min.; (7)Vibration resistance Operating extremes 10 to 50Hz , amplitude 1.0 mm, Damage limits 10 to 50Hz , amplitude 1.0 mm; (8)Shock resistance: Operating extremes 10G, Damage limits 100G.
Features
882N-1CH-C features: (1)5mm slim type miniature PCB Power Relay; (2)High rating 8A 277VAC; (3)UL/CUL, VDE approved; (4)High dielectric strength up to 4000VAC; (5)Special design for interface application and Home Appliances; (6)Comply with RoHS-Directive 2011/65/EU.
